104480-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact SKT Crimp ST Cable Mount Strip
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.12144
≥100 USD $0.11264
≥500 USD $0.106832
≥1000 USD $0.100936
≥3000 USD $0.094019
Inventory: 31084
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Lead, Tin
Mount Cable
Material COPPER ALLOY
Technical
Packaging Tape & Reel (TR)
Published 1999
Series AMPMODU Short Point
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -65°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 2.67mm
Current Rating 3A
Contact Finish Tin-Lead
Voltage - Rated AC 300V
Approval Agency CSA
Contact Gender Female
Operating Supply Voltage 300V
Contact Resistance 12mOhm
Wire Gauge 22-26 AWG
Insulation Resistance 5GOhm
ELV Non-Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 26 AWG
Contact Current Rating 3A
Contact Termination Crimp
Insulation Diameter 1.52 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Design Use POWER AND SIGNAL
Dimensions
Length 11.68mm
Contact Finish Thickness 100.0μin 2.54μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
