102917-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Headers & Wire Housings MOD IV RECP LP
PDF
/
Buying Options
Total Price: USD $1.35
Unit Price: USD $1.354066
≥1 USD $1.354066
≥10 USD $1.277419
≥100 USD $1.205108
≥500 USD $1.136903
≥1000 USD $1.072547
Inventory: 3967
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 11.3mm
Technical
Design Use POWER AND SIGNAL
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 1.016 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 27 AWG
Wire Gauge (Min) 27 AWG
Wire Gauge (Max) 32 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 27-32 AWG
Contact Resistance 12mOhm
Operating Supply Voltage 250V
Contact Gender Female
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 3A
Depth 2.15mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod IV
Published 2008
Packaging Bulk
Physical
Mount Cable
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 months ago)
Factory Lead Time 28 Weeks
