102107-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 22-26AWG 15GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5896
≥1 USD $0.5896
≥10 USD $0.57288
≥100 USD $0.461824
≥500 USD $0.358424
≥1000 USD $0.312717
≥3000 USD $0.297713
Inventory: 9153
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 20.85mm
Technical
Used With RECEPTACLE CONTACT
Cable Entry-Min 0.061 inch
Cable Entry-Max 0.061 inch
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 1.55 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Contact Resistance 12mOhm
Operating Supply Voltage 250V
Contact Gender Male
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 3A
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPMODU Mod IV
Published 2008
Packaging Bulk
Physical
Mount Cable
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 5 Weeks
