1-963745-3 image
Favorite
1-963745-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Contact PIN Crimp ST Cable Mount Loose Piece
PDF
/
Inventory: 4407
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 20 Weeks

Physical

Contact Material Copper, Tin
Mount Cable

Technical

Packaging Bulk
Published 2006
Series Junior Power Timer
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Power
Max Operating Temperature -150°C
Min Operating Temperature -40°C
HTS Code 8536.90.40.00
Orientation Straight
Shielding Unshielded
Contact Finish Gold
Approval Agency IEC, VDE
Wire Gauge 17-20 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 17 AWG
Wire/Cable Gauge 20 AWG
Contact Termination Crimp
Insulation Diameter -2.1 mm
Wire Cross Section 1 mm2
Pin or Socket Tab
Terminal Gender MALE

Dimensions

Length 27.3mm
Contact Finish Thickness 24.0μin 0.61μm
Plating Thickness 600 nm

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable
