1-962841-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Automotive Connectors 1P Pin (Male)
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.31592
≥100 USD $0.31504
≥500 USD $0.308352
≥1000 USD $0.26356
≥3000 USD $0.237213
Inventory: 35590
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tab Thickness 800μm
Contact Finish Thickness 118.1μin 3.00μm
Length 27.3mm
Technical
Terminal Gender MALE
Mating Tab Width 2.794mm
Pin or Socket Tab
Wire Cross Section 1 mm2
Insulation Diameter 2.1082 mm
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 17 AWG
ELV Compliant
Wire Gauge 17-20 AWG
Approval Agency IEC, VDE
Contact Finish Silver
Shielding Unshielded
Orientation Straight
HTS Code 8536.90.40.00
Min Operating Temperature -40°C
Max Operating Temperature 140°C
Type Power
Connector Type Connector, PCB, Signal
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Junior Power Timer
Published 2005
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Copper, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 13 Weeks
