1-917511-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 14-16AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.19888
≥100 USD $0.198528
≥500 USD $0.194304
≥1000 USD $0.166056
≥3000 USD $0.149459
Inventory: 12522
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mount Cable
Technical
Packaging Bulk
Published 2005
Series Dynamic D-3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Gender Female
Voltage - Rated 600V
Orientation Straight
Shielding Unshielded
Depth 3.64mm
Current Rating 8A
Contact Finish Tin
Contact Gender Female
Operating Supply Voltage 250V
Wire Gauge 14-16 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 14 AWG
Contact Current Rating 15A
Contact Termination Crimp
Insulation Diameter 2.8 mm
Contact Retention With
Pin or Socket Socket
Dimensions
Height 3.96mm
Length 18.3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
