1-87756-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact SKT Crimp ST Cable Mount Reel
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.365547
≥1 USD $0.365547
≥10 USD $0.34486
≥100 USD $0.325339
≥500 USD $0.306915
≥1000 USD $0.289552
Inventory: 9477
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze, Copper, Tin
Mount Cable
Technical
Packaging Tape & Reel (TR)
Published 1997
Series AMPMODU Mod IV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -65°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 640μm
Orientation Straight
Shielding Unshielded
Depth 2.03mm
Current Rating 3A
Contact Finish Gold
Voltage - Rated AC 250V
Approval Agency CSA
Contact Gender Female
Operating Supply Voltage 250V
Contact Resistance 12mOhm
Wire Gauge 22-26 AWG
Insulation Resistance 5GOhm
ELV Non-Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 22 AWG
Wire/Cable Gauge 26 AWG
Contact Current Rating 3A
Contact Termination Crimp
Insulation Diameter 1.55 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Used With WIRE TO BOARD CONNECTOR
Design Use POWER AND SIGNAL
Dimensions
Length 11.3mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
