1-87313-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 26-30AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.721105
≥1 USD $0.721105
≥10 USD $0.680287
≥100 USD $0.641779
≥500 USD $0.605455
≥1000 USD $0.571176
Inventory: 4659
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 11.3mm
Height 2.41mm
Technical
Design Use POWER AND SIGNAL
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 1.22 mm
Contact Termination Crimp
Contact Current Rating 3A
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 30 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Voltage Rating (AC) 250V
ELV Compliant
Insulation Resistance 5GOhm
Wire Gauge 26-30 AWG
Contact Resistance 12mOhm
Operating Supply Voltage 250V
Housing Color White
Contact Gender Female
Number of Contacts 12
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 3A
Depth 1.77mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Number of Rows 1
Min Operating Temperature -65°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod V
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable, Through Hole
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 10 Weeks
