1-86477-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Headers & Wire Housings MOD I RECP STMPD/RER
PDF
/
Inventory: 6358
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Bronze
Mount Through Hole
PCB Mount Retention Without
Technical
Packaging Tape & Reel (TR)
Published 2010
Series AMPMODU Mod I
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Pitch 3.803218mm
Orientation Vertical
Shielding Unshielded
Current Rating 5A
Contact Finish Tin
Contact Gender Female
Lead Length 2.85mm
Contact Resistance 12MOhm
Insulation Resistance 5GOhm
ELV Compliant
Connector Support Type CONNECTOR ACCESSORY
Contact Current Rating 5A
Contact Termination Solder, PCB
Pin or Socket Socket
Make First / Break Last No
Dimensions
Contact Finish Thickness 78.7μin 2.00μm
Plating Thickness 2.0066μm
PCB Thickness 1.78mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
