1-794608-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 20-24AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.13376
≥100 USD $0.124608
≥500 USD $0.118272
≥1000 USD $0.111848
≥3000 USD $0.104086
Inventory: 241050
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 2.54μm
Contact Finish Thickness 15.0μin 0.38μm
Length 13.73mm
Technical
Pin or Socket Pin
Insulation Diameter 1.52 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 5A
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
Plating Gold, Tin
Max Current Rating 5A
ELV Compliant
Wire Gauge 20-24 AWG
Operating Supply Voltage 250V
Contact Gender Male
Contact Finish Gold
Current Rating 5A
Depth 2.48mm
Orientation Straight
Pitch 2.54mm
Voltage - Rated 250V
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Type Stamped
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Micro MATE-N-LOK
Published 2008
Packaging Tape & Reel (TR)
Physical
Underplate Material Nickel
Number of Pins 1
Mount Cable
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 16 Weeks
