1-794607-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONTACT RCPT CRIMP 26-30AWG GOLD
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.1364
≥100 USD $0.12672
≥500 USD $0.120384
≥1000 USD $0.113784
≥3000 USD $0.105917
Inventory: 211027
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Cable
Number of Pins 1
Underplate Material Nickel
Technical
Packaging Tape & Reel (TR)
Published 2008
Series Micro MATE-N-LOK
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Stamped
Max Operating Temperature 221°C
Min Operating Temperature -40°C
Voltage - Rated 250V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 3mm
Orientation Straight
Depth 2.67mm
Current Rating 5A
Contact Finish Gold
Contact Gender Female
Operating Supply Voltage 250V
Wire Gauge 26-30 AWG
ELV Compliant
Max Current Rating 5A
Plating Gold, Tin
Wire/Cable Type Discrete
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 26 AWG
Wire/Cable Gauge 26 AWG
Contact Current Rating 5A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 1.52 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Max 0.06 inch
Cable Entry-Min 0.035 inch
Dimensions
Height 1.93mm
Length 12.53mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 2.54μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Not Applicable
