1-794226-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 22-26AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.43736
≥100 USD $0.435776
≥500 USD $0.420992
≥1000 USD $0.352968
≥3000 USD $0.330915
Inventory: 1568
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Brass
Contact Plating Gold, Tin
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2005
Series Mini-Universal MATE-N-LOK II
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Voltage - Rated 600V
Orientation Straight
Depth 2.95mm
Current Rating 9.5A
Contact Finish Gold
Approval Agency UL
Contact Gender Male
Operating Supply Voltage 600V
Contact Resistance 20mOhm
Wire Gauge 22-26 AWG
ELV Compliant
Max Current Rating 10.5A
Plating Gold, Tin
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 26 AWG
Wire/Cable Gauge 22 AWG
Contact Current Rating 10.5A
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 1.75 mm
Pin or Socket Pin
VDE Tested Yes
Dimensions
Height 2.92mm
Length 20.2mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 2.54μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
