1-770255-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact SKT Crimp ST Cable Mount Loose Piece
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.206438
≥1 USD $2.206438
≥10 USD $2.081552
≥100 USD $1.963725
≥500 USD $1.852565
≥1000 USD $1.747705
Inventory: 9295
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 20.19mm
Height 4.78mm
Technical
Used With STANDARD UNIVERSAL MATE-N-LOK(SOCKET)
Cable Entry-Min 0.13 inch
Cable Entry-Max 0.2 inch
Wire Size (Max) 14 AWG
Assembly Item Name CONTACT
Pin or Socket Pin
Contact Termination Crimp
Circuit Application Power
Wire/Cable Gauge 20 AWG
Cable Type DISCRETE WIRE
Connector Support Type CONNECTOR ACCESSORY
Plating Gold, Tin
Max Current Rating 13A
ELV Compliant
Wire Gauge 14-20 AWG
Operating Supply Voltage 600V
Approval Agency CSA; UL; VDE
Contact Finish Gold
Current Rating 19A
Depth 4.45mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature UNDERPLATING THICKNESS: (50)
Voltage - Rated 600V
Gender Female
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Connector, Pin, Power
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Universal MATE-N-LOK II
Published 2008
Packaging Bulk
Physical
Underplate Material Nickel
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 10 Weeks
