1-175217-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 20-24AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.4752
≥1 USD $0.4752
≥10 USD $0.4488
≥100 USD $0.373912
≥500 USD $0.279972
≥1000 USD $0.248028
≥3000 USD $0.232549
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Copper
Contact Plating Gold
Mount Cable
Underplate Material Nickel
Technical
Packaging Bulk
Published 2004
Series Dynamic D-3
Part Status Active
Pin or Socket Socket
Contact Retention With
Insulation Diameter 2.6 mm
Contact Termination Crimp
Contact Current Rating 15A
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 20-24 AWG
Operating Supply Voltage 250V
Contact Gender Female
Contact Finish Gold
Current Rating 15A
Depth 3.6mm
Shielding Unshielded
Orientation Straight
Gender Receptacle
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Socket
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 17.78mm
Height 3.6mm
