1-170291-1 image
Favorite
1-170291-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Automotive Connectors DLI REC CONTACT Reel of 8000
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.0968
≥1 USD $0.0968
≥10 USD $0.0836
≥100 USD $0.07744
≥500 USD $0.073568
≥1000 USD $0.069608
≥3000 USD $0.064803
Inventory: 31678
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Length 19mm
Height 3.9mm

Technical

Pin or Socket Socket
Insulation Diameter 2.413 mm
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 20 AWG
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 5A
ELV Compliant
Wire Gauge 20-22 AWG
Contact Gender Female
Contact Finish Tin
Depth 3.1mm
Shielding Unshielded
Orientation Straight
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Connector Type Connector, PCB, Signal, Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2004
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 18 Weeks
