963711-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Headers & Wire Housings MICRO TIM RECEPTACLE CONTACT
PDF
/
Inventory: 1106
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Material Copper, Ferrite, Tin
Contact Plating Tin
Mount Cable
Technical
Published 2006
Pbfree Code yes
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Socket
Max Operating Temperature -120°C
Min Operating Temperature -40°C
Gender Receptacle
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Depth 4.5mm
Current Rating 12A
Approval Agency IEC, VDE
Contact Gender Female
Contact Style BELLOWED CONTACT
Contact Resistance 4mOhm
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 17 AWG
Insulation Diameter 2.8 mm
Assembly Item Name CONTACT
Cable Entry-Max 0.0827 inch
Cable Entry-Min 0.0472 inch
Dimensions
Height 4.8mm
Length 19.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
