962945-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Automotive Connectors MICRO TIM SOCKET CONTACT
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.126158
≥1 USD $0.126158
Inventory: 56
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze, Copper, Tin
Contact Plating Tin
Mount Cable
Technical
Termination Crimp
ECCN Code EAR99
Connector Type Socket
Max Operating Temperature -120°C
Min Operating Temperature -40°C
Gender Female
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 3.2mm
Current Rating 10A
Approval Agency IEC, VDE
Contact Style BELLOWED CONTACT
Contact Resistance 4mOhm
ELV Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 17 AWG
Wire Gauge (Min) 20 AWG
Insulation Diameter -2 mm
Contact Design LOOSE
Assembly Item Name CONTACT
Cable Entry-Max 0.0827 inch
Cable Entry-Min 0.0551 inch
Dimensions
Height 3.4mm
Length 19mm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
