175063-1

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Automotive Connectors 040MLC PIN 22-20 BR/SN
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.17032
≥1 USD $0.17032
≥10 USD $0.16067
≥100 USD $0.15158
≥500 USD $0.143
≥1000 USD $0.13491
≥3000 USD $0.12727
Inventory: 5983
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 days ago)

Physical

Contact Material Brass
Contact Plating Tin
Mount Through Hole

Technical

Termination Crimp
Connector Type Connector, PCB, Pin, Signal, Tab
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 4.8mm
Approval Agency UL
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
ELV Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 20 AWG
Wire/Cable Gauge 20 AWG
Sealable No
Insulation Diameter 2.0066 mm
Contact Design LOOSE
Assembly Item Name CONTACT
Mating Tab Width 990.6μm
Rated Voltage(AC) 1000V

Dimensions

Length 19mm
Tab Thickness 640μm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
