XG5W-0232-R image
Favorite
XG5W-0232-R image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Headers & Wire Housings Reel Crimp Contacts For XG5N, Type 2
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.4224
≥1 USD $0.4224
≥10 USD $0.35904
≥100 USD $0.316448
≥500 USD $0.290752
≥1000 USD $0.2794
≥3000 USD $0.25087
Inventory: 30522
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness 5.90μin 0.150μm

Technical

Removal Tools XY2E-0003
Military Connector Accessory Name CONTACT
Pin or Socket Socket
Contact Termination Crimp
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge 24-28 AWG
Contact Gender FEMALE
Contact Finish Galvanized
Current Rating 1A
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
HTS Code 8536.90.40.00
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Connector, Signal, Socket
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series XG5N
Published 2002
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Plating Gold
Contact Material Bronze

Supply Chain

Factory Lead Time 13 Weeks
