5034291000

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN 26-30AWG CRIMP GOLD
PDF
/
Inventory: 7456
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length - Termination 0.096 inch
Contact Finish Thickness 8.00μin 0.203μm

Technical

Used With 502578, 503149
Cable Entry-Min 0.028 inch
Cable Entry-Max 0.04 inch
Wire Size (Max) 26 AWG
Assembly Item Name CONTACT
Pin or Socket Non-Gendered
Contact Design CHAIN
Contact Termination Crimp
Wire Gauge 26-30 AWG
Contact Gender MALE
Contact Finish Gold
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature UNDERPLATING THICKNESS (4), TERMINATION: TIN (39) OVER NICKEL (4)
Type Stamped
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series CLIK-Mate 503429
Published 2015
Packaging Tape & Reel (TR)

Physical

Mounting Style STRAIGHT
Material COPPER ALLOY

Supply Chain

Factory Lead Time 12 Weeks
