39-00-0084
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
MOLEX 39-00-0084 Contact, Mini-Fit Jr., 5558 Series, Pin, 16 AWG, Crimp, Phosphor Bronze
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.168027
≥1 USD $0.168027
≥10 USD $0.158516
≥100 USD $0.149538
≥500 USD $0.141081
≥1000 USD $0.133094
Inventory: 1609
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Bronze, Tin
Contact Plating Tin
Mount Cable
Technical
Packaging Bulk
Published 2005
Pbfree Code yes
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Connector, PCB, Pin, Power, Signal
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Voltage - Rated 600V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Unshielded
Depth 3.6mm
Current Rating 9A
Contact Gender Male
Contact Style SQUARE PIN
Contact Resistance 10mOhm
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Gauge 16 AWG
Halogen Free Low Halogen
Current Rating (Max) 9A
Assembly Item Name CONTACT
Cable Entry-Max 0.122 inch
Used With 5559, 30068, 42475 SERIES HOUSING
Dimensions
Height 4.5mm
Length 16.8mm
Finish Thickness 35
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
