08-70-0103
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Headers & Wire Housings PIN SPOX TERM 22-28
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.199598
≥1 USD $0.199598
≥10 USD $0.188302
≥100 USD $0.177643
≥500 USD $0.167583
≥1000 USD $0.158103
Inventory: 3422
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Cable
Technical
Packaging Bulk
Published 2000
Pbfree Code yes
Termination Crimp
ECCN Code EAR99
Connector Type Connector, PCB, Pin, Signal
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Voltage - Rated 250V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 0m
Orientation Straight
Shielding Unshielded
Depth 2.4mm
Current Rating 3A
Contact Gender Male
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 28 AWG
Wire/Cable Gauge 28 AWG
Number of Poles 1
Current Rating (Max) 3A
Assembly Item Name CONTACT
Cable Entry-Max 0.075 inch
Cable Entry-Min 0.045 inch
Dimensions
Height 2.15mm
Length 14.9mm
Finish Thickness 35
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
