08-70-0057
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN TERM FEMALE 22-28AWG TIN
PDF
/
Inventory: 980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 8.4mm
Height 2.6mm
Technical
Used With 5102-N, 5207-N, 5208-N, 5209-N
Cable Entry-Min 0.0453 inch
Cable Entry-Max 0.0748 inch
Assembly Item Name CONTACT
Current Rating (Max) 3A
Wire/Cable Gauge 28 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 28 AWG
Connector Support Type CONNECTOR ACCESSORY
Contact Style SQ PIN-SKT
Contact Gender Female
Current Rating 3A
Depth 2.4mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Connector Type Connector, PCB, Signal
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Published 2006
Physical
Mount Cable
Contact Plating Tin
Contact Material Brass
