08-50-0133

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN TERM FEMALE 22-26AWG TIN
PDF
/
Buying Options
Total Price: USD $0.05
Unit Price: USD $0.046902
≥1 USD $0.046902
≥500 USD $0.03448
≥1000 USD $0.028744
≥2000 USD $0.026363
≥5000 USD $0.024642
≥10000 USD $0.022916
≥15000 USD $0.022165
≥50000 USD $0.021796
Inventory: 9222
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Finish Thickness 100
Length 13.7mm
Height 4.79mm

Technical

Cable Entry-Max 0.065 inch
Assembly Item Name CONTACT
Current Rating (Max) 7A
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Connector Support Type CONNECTOR ACCESSORY
Max Voltage Rating (AC) 250V
Contact Resistance 10mOhm
Contact Style COMPRESSION
Contact Gender Female
Number of Contacts 1
Current Rating 4.5A
Depth 2.72mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Connector Type Connector, PCB, Signal
ECCN Code EAR99
Termination Crimp
Pbfree Code yes

Physical

Mount Cable
Contact Plating Tin
Contact Material Bronze
