0039000123
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN PIN 22-28AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.176
≥1 USD $0.176
≥10 USD $0.13992
≥100 USD $0.100584
≥500 USD $0.078716
≥1000 USD $0.063404
≥3000 USD $0.061222
Inventory: 29622
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 100.0μin 2.54μm
Technical
Rated Voltage(AC) 600V
Used With 5559 MINI-FIT JR. PLUG HOUSING, 30068 MINI-
Cable Entry-Min 0.035 inch
Cable Entry-Max 0.071 inch
Wire Size (Min) 22 AWG
Assembly Item Name CONTACT
Pin or Socket Pin
Rated Current 9A
Contact Termination Crimp
Wire Gauge 22-28 AWG
Contact Style COMPRESSION
Contact Gender MALE
Contact Finish Tin
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Additional Feature USED WITH: 42475 MINI-FIT BMI PLUG HOSUING
Type Power
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Mini-Fit Jr 5558
Packaging Bulk
Physical
Material BRASS
Supply Chain
Factory Lead Time 14 Weeks
