SPH-002T-P0.5S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 24-30AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.05456
≥100 USD $0.045408
≥500 USD $0.041888
≥1000 USD $0.040392
≥3000 USD $0.034848
Inventory: 287942
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 6.35mm
Length 5.7mm
Height 6.35mm
Technical
Assembly Item Name CONTACT
Pin or Socket Socket
Contact Design STRIP OR LOOSE
Wire/Cable Diameter 1.5 mm
Contact Termination Crimp
Wire/Cable Gauge 24 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 30 AWG
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 2A
Max Voltage Rating (AC) 100V
Insulation Resistance 1GOhm
Wire Gauge 24-30 AWG
Contact Resistance 10mOhm
Contact Style BELLOWED CONTACT
Working Voltage 100V
Contact Finish Tin
Current Rating 2A
Depth 1.5mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 100V
HTS Code 8536.90.40.00
Gender Male
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Resistance 10mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PH
Packaging Cut Tape (CT)
Physical
Weight 28.349523g
Contact Material Bronze
Supply Chain
Factory Lead Time 16 Weeks
