DF13-2630SCF image
Favorite
DF13-2630SCF image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description CONN CONTACT 26-30AWG CRIMP TIN
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.04224
≥100 USD $0.034496
≥500 USD $0.032032
≥1000 USD $0.030888
≥3000 USD $0.026682
Inventory: 474386
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper
Mounting Style STRAIGHT

Technical

Packaging Cut Tape (CT)
Published 2005
Series DF13
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector, PCB, Signal
Resistance 30mOhm
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Beige
Voltage - Rated 150V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Current Rating 1A
Contact Finish Tin
Approval Agency UL
Contact Gender Female
Contact Style BELLOWED CONTACT
Contact Resistance 30mOhm
Wire Gauge 26-30 AWG
Insulation Resistance 500MOhm
Connector Support Type CONNECTOR ACCESSORY
Cable Type UL1571, UL1061
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 26 AWG
Wire/Cable Gauge 26 AWG
Contact Termination Crimp
Pin or Socket Socket
Assembly Item Name CONTACT
Wire Size (Min) 32 AWG
Cable Entry-Max 0.039 inch
Cable Entry-Min 0.026 inch

Dimensions

Height 1.65mm
Length 3.7mm

Compliance

REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
