A3B-2630SCC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 26-30AWG CRIMP GOLD
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.12056
≥100 USD $0.106656
≥500 USD $0.099616
≥1000 USD $0.0924
≥3000 USD $0.081778
Inventory: 1369
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Bronze
Mounting Style STRAIGHT
Technical
Packaging Bulk
Published 2008
Series A3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector, PCB, Signal
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Voltage - Rated 200V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Current Rating 1A
Contact Finish Gold
Contact Gender Female
Contact Style BELLOWED TYPE
Contact Resistance 15mOhm
Wire Gauge 26-30 AWG
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 30 AWG
Wire/Cable Gauge 30 AWG
Contact Termination Crimp
Pin or Socket Socket
Assembly Item Name CONTACT
Dimensions
Length - Termination 0.09 inch
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
