8-146455-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 39POS 0.1 STACK T/H TIN
PDF
/
Inventory: 9861
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Stack Height 5.08mm
Length - Tail 0.110 2.800mm
Contact Finish Thickness - Post (Mating) 100.0μin 2.54μm
Length - Post (Mating) 0.130 3.300mm
Length - Overall Pin 0.440 11.176mm
Length - Stack Height 0.200 5.080mm
Technical
Stackable Yes
Mating Post Length 2.7686mm
Contact Current Rating 3A
Plating Tin
ELV Compliant
Insulation Resistance 5GOhm
Contact Finish - Post (Mating) Tin
Lead Length 11.18mm
Housing Color Black
Number of Contacts 39
Approval Agency CSA
Orientation Vertical
Pitch 0.100 2.54mm
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 39
Connector Type Header, Pin, Plug
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod II
Published 2006
Packaging Bulk
Physical
PCB Mount Retention Without
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mounting Type Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
