Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description CONN HEADR 44POS .100 DUAL ROW
PDF
/
Inventory: 9962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Stack Height 25.4mm
Length - Tail 0.100 2.540mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Post (Mating) 0.330 8.382mm
Length - Overall Pin 1.430 36.322mm
Contact Finish Thickness - Mating 381 nm
Length - Stack Height 1.000 25.400mm
Length 36.322mm

Technical

Stackable Yes
Mating Post Length 8.38mm
Contact Current Rating 3A
Plating Gold
ELV Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5GOhm
Contact Finish - Post (Mating) Gold
Lead Length 36.32mm
Housing Color Black
Number of Contacts 44
Approval Agency CSA
Orientation Vertical
Pitch 0.100 2.54mm
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 44
Connector Type Header, Pin, Plug
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod II
Published 2011
Packaging Bulk

Physical

PCB Mount Retention Without
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 months ago)
Factory Lead Time 8 Weeks
