7-146497-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 48 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 4365
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Housing Material Thermoplastic
Technical
Packaging Bulk
Published 2011
Series AMPMODU Mod II
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 48
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 2
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 48
Orientation Vertical
Current Rating 3A
Approval Agency CSA
Contact Gender MALE
UL Flammability Code 94V-0
Lead Length 26.16mm
Contact Finish - Post (Mating) Gold
Insulation Resistance 5GOhm
Row Spacing 0.100 (2.54mm)
ELV Compliant
Contact Current Rating 3A
Mating Post Length 8.38mm
Stackable Yes
Dimensions
Length 26.162mm
Length - Stack Height 0.600 15.240mm
Length - Overall Pin 1.030 26.162mm
Length - Post (Mating) 0.330 8.382mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Tail 0.100 2.540mm
Stack Height 15.24mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
