7-146459-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 22 MODII HDR SRST UNSHRD STKG
PDF
/
Inventory: 2015
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mounting Type Through Hole
Contact Shape Square
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Technical
Packaging Bulk
Published 2014
Series AMPMODU Mod II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 22
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Pitch 0.100 2.54mm
Orientation Vertical
Current Rating 3A
Approval Agency CSA
Number of Contacts 22
Housing Color Black
Lead Length 15.67mm
Contact Finish - Post (Mating) Tin
Insulation Resistance 5GOhm
ELV Compliant
Contact Current Rating 3A
Mating Post Length 2.7686mm
Stackable Yes
Dimensions
Length - Stack Height 0.400 10.160mm
Length - Overall Pin 0.617 15.672mm
Length - Post (Mating) 0.107 2.718mm
Contact Finish Thickness - Post (Mating) 100.0μin 2.54μm
Length - Tail 0.110 2.800mm
Stack Height 10.16mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
