6-146497-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 30 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 4401
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 15.24mm
Length - Tail 0.100 2.540mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Post (Mating) 0.330 8.382mm
Length - Overall Pin 1.030 26.162mm
Length - Stack Height 0.600 15.240mm
Length 26.162mm
Technical
Stackable Yes
Mating Post Length 8.38mm
Contact Current Rating 3A
ELV Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5GOhm
Contact Finish - Post (Mating) Gold
Lead Length 26.16mm
Contact Gender MALE
Approval Agency CSA
Current Rating 3A
Orientation Vertical
Total Number of Contacts 30
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 30
Connector Type Header, Pin, Plug
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AMPMODU Mod II
Published 2011
Packaging Bulk
Physical
Housing Material Thermoplastic
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
