6-146455-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 18POS 0.1 STACK T/H TIN
PDF
/
Inventory: 2184
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Plating Tin
Mounting Type Through Hole
Contact Shape Square
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
PCB Mount Retention Without
Technical
Packaging Bulk
Published 2012
Series AMPMODU Mod II
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 18
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Pitch 0.100 2.54mm
Orientation Vertical
Approval Agency CSA
Number of Contacts 18
Housing Color Black
Lead Length 11.18mm
Contact Finish - Post (Mating) Tin
Insulation Resistance 5GOhm
ELV Compliant
Plating Tin
Contact Current Rating 3A
Mating Post Length 2.7686mm
Stackable Yes
Dimensions
Length - Stack Height 0.200 5.080mm
Length - Overall Pin 0.440 11.176mm
Length - Post (Mating) 0.130 3.300mm
Contact Finish Thickness - Post (Mating) 100.0μin 2.54μm
Length - Tail 0.110 2.800mm
Stack Height 5.08mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
