2-146510-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 48 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 5239
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Tail 0.330 8.382mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Post (Mating) 0.330 8.382mm
Length - Overall Pin 1.430 36.322mm
Length - Stack Height 0.770 19.558mm
Plating Thickness 15μin
Length 36.322mm
Technical
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 750VAC V
Body/Shell Style RECEPTACLE
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Gold
UL Flammability Code 94V-0
Operating Temperature (Min) -65°C
Contact Gender MALE
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Total Number of Contacts 48
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Number of Positions 48
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series AMPMODU Mod II
Published 2011
Packaging Bulk
Physical
Insulation Material THERMOPLASTIC
Mounting Type Through Hole
Mount Through Hole
Contact Material COPPER ALLOY
