2-146460-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 20 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 1964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 11.43mm
Length - Tail 0.110 2.800mm
Contact Finish Thickness - Post (Mating) 100.0μin 2.54μm
Length - Post (Mating) 0.057 1.448mm
Length - Overall Pin 0.617 15.672mm
Length - Stack Height 0.450 11.430mm
Technical
Stackable Yes
Mating Post Length 2.7686mm
Contact Current Rating 3A
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5GOhm
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Tin-Lead
Lead Length 15.67mm
UL Flammability Code 94V-0
Body Breadth 0.092 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Approval Agency CSA
Reliability COMMERCIAL
Number of Conductors ONE
Orientation Vertical
Total Number of Contacts 20
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 20
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Series AMPMODU Mod II
Published 2012
Packaging Bulk
Physical
Housing Material Thermoplastic
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Lead, Nickel, Tin
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 8 Weeks
