146500-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 04 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 6850
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Brass
Mounting Type Through Hole
Contact Shape Square
Housing Material Thermoplastic
PCB Mount Retention Without
Technical
Packaging Bulk
Published 2011
Series AMPMODU Mod II
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Header, Pin, Plug
Number of Positions 4
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 2
Additional Feature STACKING & W/O MOUNTING EARS
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 4
Orientation Vertical
Current Rating 3A
Number of Conductors ONE
Reliability COMMERCIAL
Approval Agency CSA
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
Lead Length 28.702mm
Body Depth 0.7 inch
Rated Current (Signal) 3A
Contact Finish - Post (Mating) Gold
Contact Style SQ PIN-SKT
Insulation Resistance 5GOhm
Row Spacing 0.100 (2.54mm)
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Contact Current Rating 3A
Mating Post Length 8.38mm
Stackable Yes
Dimensions
Plating Thickness 15μin
Length - Stack Height 0.700 17.780mm
Contact Finish Thickness - Mating 381 nm
Length - Overall Pin 1.130 28.700mm
Length - Post (Mating) 0.330 8.382mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Termination 0.33 inch
Length - Tail 0.100 2.540mm
Stack Height 17.78mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
