8-146496-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 8832
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Thermoplastic
Technical
Packaging Bulk
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 70
Max Operating Temperature -125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 2
Pitch 2.54mm
Orientation Vertical
Approval Agency CSA, UL
Row Spacing - Mating 2.54 mm
Number of Contacts 70
Housing Color Black
Lead Length 26.16mm
ELV Compliant
Mating Post Length 2.79mm
Dimensions
Length 26.162mm
Length - Tail 2.794mm
Stack Height 20.32mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
