5-146471-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 5391
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Contact Shape Square
Housing Material Thermoplastic
Technical
Packaging Bulk
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 8
Max Operating Temperature -125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Pitch 2.54mm
Orientation Vertical
Current Rating 3A
Approval Agency CSA, UL
Number of Contacts 8
Housing Color Black
Lead Length 28.7mm
ELV Compliant
Mating Post Length 2.79mm
Dimensions
Length 28.702mm
Length - Tail 2.794mm
Stack Height 22.86mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
