5-146471-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 2054
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 22.86mm
Length - Tail 2.794mm
Length 28.702mm
Technical
Mating Post Length 2.79mm
ELV Compliant
Lead Length 28.7mm
Housing Color Black
Number of Contacts 7
Approval Agency CSA, UL
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature -125°C
Number of Positions 7
Connector Type Header, Pin, Plug
Termination Solder
Packaging Bulk
Physical
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Tin
Contact Material Brass
