4-146481-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
40 MODII HDR SRST UNSHRD STKG
PDF
/
Inventory: 6634
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Brass
Contact Plating Gold
Mount Through Hole
Contact Shape Square
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
PCB Mount Retention Without
Technical
Packaging Bulk
JESD-609 Code e4
Pbfree Code no
Termination Through Hole
ECCN Code EAR99
Connector Type Header, Pin, Plug
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Number of Rows 1
Gender Male
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN LEAD (200) OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reliability COMMERCIAL
Approval Agency CSA
Body Length or Diameter 3.984 inch
Number Of PCB Rows 1
Number of Contacts 40
PCB Contact Pattern RECTANGULAR
Body Breadth 0.092 inch
UL Flammability Code 94V-0
Housing Color Black
Lead Length 36.32mm
Contact Style SQ PIN-SKT
Insulation Resistance 5GOhm
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Mating Post Length 8.38mm
Contact Rating (Current) 3A
Stackable Yes
Dimensions
Contact Finish Thickness - Mating 381 nm
Length - Tail 2.54mm
Stack Height 25.4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
