RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description 40 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 8475
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Mating Information NO
UL Flammability Code 94V-0
Housing Color Black
Lead Length 23.62mm
Contact Style SQ PIN-SKT
Insulation Resistance 5GOhm
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Mating Post Length 8.38mm
Contact Rating (Current) 3A
Stackable Yes
PCB Contact Pattern RECTANGULAR
Number of Contacts 40
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 1.984 inch
Approval Agency CSA
Reliability COMMERCIAL
Number of Conductors ONE
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature AMPMODU
Gender Male
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Through Hole
Pbfree Code no
JESD-609 Code e0
Packaging Bulk

Dimensions

Plating Thickness 15μin
Contact Finish Thickness - Mating 381 nm
Length - Tail 2.54mm
Stack Height 12.7mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0

Physical

PCB Mount Retention Without
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Gold
Contact Material COPPER ALLOY

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
