2-146485-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
AMPMODU Rectangular Connector Board Spacer
PDF
/
Inventory: 7262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 6.35mm
Plating Thickness 100μin
Technical
Mating Post Length 2.79mm
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Lead Length 12.03mm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender MALE
PCB Contact Pattern RECTANGULAR
Number of Contacts 52
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Approval Agency CSA, UL
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMPMODU
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature -125°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Through Hole
Pbfree Code no
JESD-609 Code e0
Physical
Mounting Style STRAIGHT
Housing Material Thermoplastic
Mounting Type BOARD
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
