146471-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
AMPMODU Rectangular Connector Board Spacer
PDF
/
Inventory: 2917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Style STRAIGHT
Housing Material Thermoplastic
Contact Shape Square
Mounting Type BOARD
Contact Plating Lead, Tin
Contact Material Brass
Technical
JESD-609 Code e0
Pbfree Code no
Termination Through Hole
ECCN Code EAR99
Connector Type Header, Pin, Plug
Max Operating Temperature -125°C
Min Operating Temperature -65°C
Number of Rows 1
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Vertical
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Body Length or Diameter 0.584 inch
Number Of PCB Rows 1
Number of Contacts 6
PCB Contact Pattern RECTANGULAR
Mating Information NO
Body Breadth 0.092 inch
Contact Gender MALE
UL Flammability Code 94V-0
Housing Color Black
Lead Length 28.7mm
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Mating Post Length 2.79mm
Dimensions
Stack Height 22.86mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
