1-146497-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
STACKING & W/O MOUNTING EARS Rectangular Connector Stacker
PDF
/
Inventory: 2611
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 15.24mm
Length - Tail 2.54mm
Plating Thickness 15μin
Technical
Stackable Yes
Contact Rating (Current) 3A
Mating Post Length 8.38mm
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5GOhm
Contact Style SQ PIN-SKT
Lead Length 26.16mm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender MALE
PCB Contact Pattern RECTANGULAR
Number of Contacts 34
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 1.684 inch
Approval Agency CSA
Reliability COMMERCIAL
Number of Conductors ONE
Current Rating 3A
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature STACKING & W/O MOUNTING EARS
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Through Hole
JESD-609 Code e0
Packaging Carton
Physical
PCB Mounting Orientation Vertical
Mounting Style STRAIGHT
Housing Material Thermoplastic
Contact Shape Square
Mounting Type BOARD
Contact Plating Gold
Contact Material Brass
