7-146496-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 9740
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 20.32mm
Length - Tail 2.794mm
Length 26.162mm
Technical
Mating Post Length 2.79mm
ELV Compliant
Lead Length 26.16mm
Housing Color Black
Number of Contacts 40
Row Spacing - Mating 2.54 mm
Approval Agency CSA, UL
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature -125°C
Number of Positions 40
Connector Type Header, Pin, Plug
Termination Solder
Packaging Bulk
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Tin
Contact Material Brass
