6-146493-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 38 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 5975
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Housing Material Thermoplastic
Technical
Packaging Bulk
Termination Solder
Connector Type Header, Pin, Plug
Number of Positions 38
Max Operating Temperature -125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 2
Pitch 2.54mm
Orientation Vertical
Current Rating 3A
Approval Agency CSA, UL
Row Spacing - Mating 2.54 mm
Number of Contacts 38
Housing Color Black
Lead Length 23.62mm
ELV Compliant
Mating Post Length 2.79mm
Dimensions
Length 23.622mm
Length - Tail 2.794mm
Stack Height 17.78mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
