5-146491-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 10 MODII HDR DRST UNSHRD STKG
PDF
/
Inventory: 5611
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Stack Height 15.24mm
Length - Tail 2.794mm
Length 20.7518mm
Technical
Mating Post Length 2.79mm
ELV Compliant
Lead Length 20.75mm
Housing Color Black
Number of Contacts 10
Row Spacing - Mating 2.54 mm
Approval Agency CSA, UL
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature -125°C
Number of Positions 10
Connector Type Header, Pin, Plug
Termination Solder
Part Status Discontinued
Published 2009
Packaging Bulk
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 3 Weeks
