146508-3

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description AMPMODU Rectangular Connector Board Spacer
PDF
/
Inventory: 2426
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

PCB Contact Pattern RECTANGULAR
Housing Color Black
Number of Contacts 6
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Approval Agency CSA, UL
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature AMPMODU
Gender Male
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature -125°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Pbfree Code no
JESD-609 Code e0
Published 2011
Packaging Bulk
Mating Post Length 2.79mm
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Lead Length 36.32mm

Physical

Housing Material Thermoplastic
Mount Through Hole
Contact Plating Lead, Tin
Contact Material Brass

Supply Chain

Factory Lead Time 14 Weeks

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Stack Height 30.48mm
Plating Thickness 100μin
