146499-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
AMPMODU Rectangular Connector Stacker
PDF
/
Inventory: 5640
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Lead, Tin
Mounting Type BOARD
Housing Material Thermoplastic
Mounting Style STRAIGHT
Technical
JESD-609 Code e0
Pbfree Code no
Termination Through Hole
ECCN Code EAR99
Connector Type Header, Pin, Plug
Max Operating Temperature -125°C
Min Operating Temperature -65°C
Number of Rows 2
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Vertical
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 2
Number of Contacts 4
PCB Contact Pattern RECTANGULAR
Mating Information NO
Contact Gender MALE
Housing Color Black
Lead Length 28.7mm
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Mating Post Length 2.79mm
Dimensions
Plating Thickness 100μin
Stack Height 22.86mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
